HDD ENVIRONMENTAL
Details
Nonmetallic Tool Joint Compound
HDD Environmental is a premium quality, nonmetallic, non-conductive compound that incorporates natural extreme pressure and antiwear additives. These components are carefully blended into JET-LUBE’s all-weather calcium complex base grease. The innovative base grease provides the added benefits of low-temperature application and service, excellent adhesion to wet steel surfaces, resistance to water wash-off, and resilience against various drilling muds.
HDD Environmental solids package is formulated to prevent excessive circumferential makeup by increasing the coefficient of friction under compressive forces. As stress levels rise above 50% of yield, the friction factor increases, limiting downhole makeup. Full hydraulic joint efficiency is maintained allowing joint shoulder faces to mate completely without standoff or deformation. HDD Environmental, with frictional properties like KOPR-KOTE®, has been designed to utilize the makeup charts in API RP7G by multiplying the listed torque by 1.15. Adjusting make-up torque based on the connection manufacturer recommendations, prior experience, standard operating procedures, and specifications is advised.
Benefits:
- Excellent performance on high-chrome or nickel alloys
- Contains no metals
- Extreme-pressure additives provide additional protection against seizing and galling
- Nonconductive for MWD applications
Pumpability makes it ideal for HDD and other construction drilling applications
Specifications:
Base Materials: Calcium Complex / Petroleum
Friction / Nut-Factor: Friction Factor* Relative to API RP 7G 1.0
Certifications: NSF-61 Certified
Service Rating: -40°F (-40°C) to 350°F (177°C)
